Home / Products / Flatbed Semi Trailer /

40ft 3 And 4axles 48ft 53ft Platform Flatbed Container Semi Trailer With Tractor Steel Floor 3-5mm Diamond Plate

Brand Name:	Xianmang
Price:	CN¥65,217.60/sets 1-4 sets

Detail Information

Product Description

Detail Information

Place of Origin:

Shandong, China

Use:

Truck Trailer

Type:

Semi-Trailer

Material:

Steel

Size:

12400-16400 *2500 * 1550mm

Max Payload:

60T

Product Name:

Transportation Container Trailer

Quantity OF Axle:

2~4

Capacity:

30~60T

Paiting:

Optional

Tire Specification:

12R22.5/11.00R20

Whellbase(mm):

6800+1310+1310

Kingpin:

50#90#

Floor:

3-5mm Diamond Plate

Electrical System:

Voitage:24v

Suspension:

Mechanical Suspension

Highlight:

40ft flatbed container semi trailer

48ft flatbed container semi trailer

53ft flatbed container semi trailer

Product Description

Flatbed semi trailer has a reasonable structure, reliable operation, and beautiful appearance, giving full play to the full potential of the vehicle. The various products can meet customers' individual needs.

Why choose ZW Group for cooperation ?

The quality of most of ZW Group semi trailer are the same as or better than CIMC and Titan

For example, the quality of Flatbed semi trailer,Low bed Semi Trailer, Fuel tanker semi Trailer, Detachable Gooseneck Lowboy (Frond loading) Trailer, and Container Side Loader far exceed the quality of CIMC.

Secondly, ZW Trailer is the manufacturer that exports the most semi-trailers in China, exporting more than 2,600 units every year.

Choosing ZW Group, we will help you resolve all from production, packing and shipping to after-sales services, with more favorable price.

Details Images

Xianmang Tranding Co.;Ltd Flatbed Semi Trailer is the main load-bearing part, which is composed of the main beam, side beam, beam, bottom plate, suspension and so on. The steel plate in the middle of the beam is made of Q345B manganese steel with a thickness of 8mm.

Production Processing Plant

Flatbed Semi Trailer is mainly used to carry heavy duty containers.With better carrying capacity, increased off-road capability, mobility, road safety and longer service life.

We have professional technicians to operate.The chassis is a frame of welded beams and beams with mounting brackets and equipment to hold and securely hold the load.With side protection and support.

Flatbed Tractor Trailer Features

The flatbed trailer has a reinforced frame made of high-strength steel HG60, a thickened floor, a reliable chassis and an efficient braking system.

Product Paramenters

Dimensions (LxWxH)	12400-18000×2500-3200×1500-1550mm
Tare Weight	8000kg--14000kg
Loading Capacity	40T
Axle Weight Load	13T
Axle number	2
Axle Brand	Fuwa/BPW/Optional upon choice
Suspension	Common mechanical Or Air suspension
King Pin	2" or 3.5" traction pin
Support legs	28T
Wheel Rim	8.5-20,9.0-20,8.28-22.5,9.0-22.5 steel wheel rim/optional upon choice
Wheelbase	7180/6680/6260+1310+1310mm
Steel Spring	10-13 pieces per axle
Twist lock	12 sets of ISO twist lock for 120ft,220ft,1*40ft container
Landing Gear	Manual operating, Heavy duty landing gear (Brand Optional upon chioce)
Floor	3-5 Diamond steel plate
Accessories	1 Set standard tool box
Light	Tail lamp with turn signal, brake light & reflector, side lamp etc.
Painting	1coat of anticorrosive prime, twice coats of final paint

Customer Photos

Packing and Shipping
